描述
|
型式
（本体×口宽W）
|
允许转矩
|
外 尺
宽 寸
mm
|
厚
度
mm
|
适用型式
|
|
RH18D×5.5
|
N.m
1.5
|
10.5
|
5
|
CL6N.CSP6N,CSF7N,CL1.5N
CSP1.5N,CL12N,CSP12N
CSF14N,CL3N,CSP3N,
CDB7N-S,CDB14N-S
CEM9N2
|
|
RH18D×6
|
2.4
|
11
|
|
RH18D×7
|
3.6
|
12
|
6
|
|
RH18D×8
|
7.2
|
13.5
|
|
RH18D×10
|
12.2
|
15.5
|
7
|
|
RH18D×11
|
14
|
17
|
|
RH18D×12
|
19
|
|
RH18D×13
|
|
RH10D×8
|
7.2
|
12.5
|
6
|
CL25N.YCL12N,PCL25N,
CSP25N.YCL23N,
CF25N
CDB25N-S
CEM18N2
|
|
RH10D×10
|
12.2
|
15.5
|
7
|
|
RH10D×11
|
20
|
17
|
8
|
|
RH10D×12
|
25
|
18
|
|
RH10D×13
|
19
|
|
RH10D×14
|
20
|
|
RH10D×16
|
22
|
|
RH10D×17
|
24
|
|
RH10D×18
|
25
|
|
RH10D×19
|
26
|
|
RH10D×21
|
28
|
|
RH10D×22
|
29
|
|
RH12D×8
|
7.2
|
15
|
5
|
CTA50.CTB50.
CL50N,YCL45N.
CEM45N2.CSP50N.YCL70N
PCL50N,CF50N.CDB50N-S
|
|
RH12D×10
|
12.2
|
16
|
|
RH12D×11
|
20
|
18
|
5.5
|
|
RH12D×12
|
29.5
|
20
|
6.5
|
|
RH12D×13
|
21
|
|
RH12D×14
|
59
|
20
|
10
|
|
RH12D×16
|
70
|
24
|
12
|
|
RH12D×17
|
25
|
|
RH12D×18
|
26
|
|
RH12D×19
|
26
|
|
RH12D×21
|
29
|
13
|
|
RH12D×22
|
30
|
|
RH15D×12
|
29.5
|
19
|
7
|
CTA100.CTB100.
CL100N.CL50N.PCL100N
PCL50N.CL140N.YCL190N.
PCL140N,CSP100N,CSP50N.
CSP140N.YCL140N
CF100N,CEM90N2.
CDB100N-S
|
|
RH15D×13
|
20.5
|
|
RH15D×14
|
59
|
22
|
8
|
|
RH15D×16
|
25
|
|
RH15D×17
|
100
|
26
|
10
|
|
RH15D×18
|
27
|
|
RH15D×19
|
140
|
28
|
13
|
|
RH15D×21
|
31
|
|
RH15D×22
|
|
RH15D×24
|
34
|
|
RH15D×27
|
37
|
|
RH15D×30
|
41
|
|
RH19D×14
|
59
|
22.5
|
8
|
CTA200,CTB360.
CL280N,CL420N.
CSP200N,
CF150N,CEM180N2,
CDB200N-S
|
|
RH19D×17
|
100
|
27
|
10
|
|
RH19D×18
|
28
|
11
|
|
RH19D×19
|
166
|
29
|
|
RH19D×21
|
32
|
13
|
|
RH19D×22
|
200
|
|
RH19D×24
|
35
|
|
RH19D×27
|
39
|
15
|
|
RH19D×30
|
41
|
|
RH19D×32
|
44
|
|
RH19D×34
|
47
|
|
RH19D×36
|
49
|
|
RH19D×41
|
55
|
|
RH22D×19
|
166
|
30
|
14
|
CTA360.CTB360,
CL280N,CL420N,
CSP280N,CSP420N,
CF230N,CEM360N2,
CEM500N2.
CDB300N-S,CDB420N-S
CTB500
|
|
RH22D×22
|
255
|
34
|
|
RH22D×24
|
37
|
15
|
|
RH22D×27
|
490
|
41
|
17
|
|
RH22D×30
|
500
|
44
|
|
RH22D×32
|
45
|
|
RH22D×34
|
49
|
|
RH22D×36
|
51
|
|
RH22D×41
|
57
|
|
RH22D×46
|
62
|
|
RH27D×22
|
255
|
38
|
14
|
CLE550N.
CLE750N |
|
RH27D×24
|
350
|
15
|
|
RH27D×27
|
490
|
42
|
16
|
|
RH27D×30
|
670
|
46
|
19
|
|
RH27D×32
|
750
|
48
|
20
|
|
RH27D×34
|
670
|
51
|
|
RH27D×36
|
750
|
52
|
21
|
|
RH27D×41
|
58
|
22
|
|
RH27D×46
|
64
|
24
|
|
RH27D×50
|
69
|
26
|
|
RH32D×27
|
490
|
43
|
16
|
CTB50,
CLE850N,
CLE1200N,
CF850N,CEM850N2 |
|
RH32D×30
|
670
|
46.5
|
18
|
|
RH32D×32
|
860
|
49
|
|
RH32D×34
|
52
|
|
RH32D×36
|
1200
|
53
|
24
|
|
RH32D×41
|
59
|
|
RH32D×46
|
65
|
|
RH32D×50
|
69
|
27
|
|
RH32D×55
|
75
|
29
|
|
RH32D×60
|
80
|
|
